Energy and Power Project
The Value We Bring to Our Customer
9,821
Storage Locations
99.9%
Picking Accuracy
Fast
Return on Investment
Energy and Power Project
Our customer is a leading enterprise of energy and power intelligence in China. For strategic spare parts of high-value goods, the company transformed its two floors old warehouse in Nanjing into an autonomous warehouse. Considering many factors such as storage space and picking efficiency, HAIPICK system helped realized autonomous management of the warehouse.
--Low manual picking efficiency and error prone
--Low storage space and low density
--Information management is difficult
Our Solution
--Robot quantity & type: 8 units, A42
--Charging stations：4
--Workstation type & quantity: 6 on-shelving picking workstation
--Shelving height: 2,800mm
--Case type/size: tote 600mm(L)×400mm(W)×200mm(H); 600mm(L)×400mm(W)×280mm(H)
--Warehouse area: 1,700㎡, achieved 9,821 storage locations
--3.115m HAIPICK robots were customized to maximize the utilization of storage space in the 3.2m high warehouse, the maximum pickup height is 2.85m
--It realizes goods-to-person, and semi-automatic distribution through the put-to-light system, which greatly improves the picking efficiency and accuracy.
--Buffer shelves are used for inbound and outbound to reduce manual operations
--It supports the simultaneous storage and picking of two different sizes of cases to maximize the material storage density
--HAIPICK system connects with customer WMS to realize digitalization of information
