Jack Sewing Machine
The Value We Bring to Our Customer
1,470
Storage Locations
96 cases
Picking Efficiency Per Hour
160 cases
Inbound Efficiency Per Hour
99.9%
Picking Accuracy
Jack Sewing Machine
Jack Sewing Machine is one of the largest enterprises in the global sewing industry. This project provides a pilot for autonomous storage in the raw material warehouse of Jack's latest cluster factory. The project focuses on the storage raw material and the picking of prepared material from the side assembly line. The warehouse has many kinds of materials that are difficult to managed, manual operations delivers low efficiency, and requires mixed storage of totes and cartons.
--There are many kinds of materials and it is difficult to manage
--Manual management of original warehouse, complicated operation
--There are many packing sizes, including totes and cartons, and the supplier can use the material boxes for turnover
Our Solution
--Robot quantity & type: 4 units, A42N
--Charging stations：2
--Workstation type & quantity: on-conveyor picking workstation
--Shelving area: 2,800
--Case type/size: Totes 600mm(L)×400mm(W)×200mm(H)
--Warehouse area: 300㎡, storage area: 180㎡, achieved 1,470 storage locations
--System picking efficiency: 96 cases/hour
--System inbound efficiency: 160 cases/hour
--Suitable for totes and cartons
