China’s Largest Online Retailer
The Value We Bring to Our Customer
27,000
Storage Locations
3 times
Increase Picking Efficiency
9 cases
Storage Density Per Square Meter
1,206 pieces
Workstation Efficiency Per Hour
China’s Largest Online Retailer
China’s largest online retailer operates more than 1,300 warehouses globally and 41 “Asia No. 1” large-scale intelligent logistics centers in China. The company put into use the China's first 5G intelligent logistics park. The company’s warehouse adopts different solutions which are costly, complex. Some of them include too many conveyor lines resulting in high cost and inconvenient picking operations. HAI ROBOTICS solutions enables higher efficiency through low-cost investment.
--Manual operation efficiency is low
--High labor cost; it is necessary to reduce the cost and increase efficiency
--Difficulty finding a matching automation solution
Our Solution
--Robot quantity & type: 65 units, A42
--Charging stations：25 units
--Workstation type & quantity: 15 sets U-shaped on-conveyor workstation
--Shelving height: 4,300mm
--Storage unit type/size: Tote 600mm(L)×400mm (W) ×300mm (H)
--Warehouse area: 3,800m²; Storage area: 3,000m²; Provided 27,000 storage locations, storage density is increased by 30%, the storage density of goods reaches 9 cases/m²
--Picking efficiency increased by 3 times, and the picking efficiency of a single workstation increased up to 1,206 pieces/hour
--The system outbound and inbound efficiency increased up to 1,880 cases/hour, and the number of outbound and inbound orders increased to 8,318 pieces/hour, significantly reducing time
--Intelligent scheduling improves robot efficiency. The handling efficiency of a single robot is 28.9 cases/hour
--The solution exceeds the timeliness and order volume requirements of the customer, especially for double 11 shopping festival.
