Large Pharmaceutical Company
The Value We Bring to Our Customer
17,811
Storage Locations
593 cases
Outbound Efficiency Per Hour
334 cases
Replenishment Efficiency Per Hour
99.9%
Picking Accuracy
Large Pharmaceutical Company
The customer operates more than 7,500 varieties of medical patents in China, including antibiotics, chemical preparations, health products and medical devices. With more than 40 retail chain pharmacies the customer carried out the overall automation transformation of its logistics center in Licang. It includes the transformation of pallet stacker, pallet conveying line, pallet inbound and outbound, wood stacking robot, sell piece picking G2P system, and conveyor case sorting system. With the flexible HAIPICK system allowed the customer was able to build an intelligent pharmaceutical logistics center.
--Low storage density
--Low order picking efficiency
--High labor intensity
Our Solution
--Robot quantity & type: 28 units, A42
--Charging stations：7
--Workstation type & quantity: 13 on-shelving picking workstation
--Shelving height: 3,600mm
--Storage unit type/size: Tote 600mm(L)×400mm (W) ×300mm (H)
--Warehouse area: 1,887㎡, achieved 17,811 storage locations in the existing warehouse
--The outbound sorting efficiency is 593 (cases/hour); The replenishment warehousing efficiency is 334 cases/h
--The empty case delivery efficiency is 334 cases/h; greatly reducing the inbound time
--Complete the automation of picking area
--Reduce labor input
