Qiaodan
The Value We Bring to Our Customer
31,230
Storage Locations
3 times
Increase Mixed Case Picking Efficiency
600 pieces
Return Putaway Efficiency Per Hour Per Person
99.9%
Picking Accuracy
Qiaodan
The warehouse automation project of Qiaodan takes place in its newly invested logistics park. The logistics park has a total of 8 floors. It is planned to be used for B2B business in some regions and B2C business across the country, as well as warehousing management of e-commerce return orders. The warehouse inventory is mainly shoes and clothing. The company expects to introduce the return business of e-commerce in August 2020 and undertake some B2C business in early 2021.
--Low labor efficiency, manual picking realizes 100-120 pieces/hour/person
--Manual warehouse storage density is low, and the effective picking area is small
--Too many return processing steps and the putaway efficiency is low, overall only 50 pieces/hour/person
--Use manual paper picking, difficult to guarantee the accuracy and timeliness of information and data
--The number of SKUs in the return warehouse is low, but with a large variety, which makes it difficult for manual picking
Our Solution
--Robot quantity & type: 26 units, A42L
--Charging stations：9
--Workstation type & quantity: Outbound: 1 conveyor ring 3 workstations + 4 HAIPORT
--Inbound: 1 conveyor ring 3 workstations
--Shelving height: 5,300mm
--Storage unit: totes 650mm(L)×440mm(W)×400mm(H)
--Shelving area of 4,300㎡ provided 31,230 storage locations
--Case-to-person method, B2C picking efficiency achieves 420 pieces/hour/person
--5.3m high shelves increase storage density by 0.5 times
--Autonomous putaway of returns + case-to-person picking, achieves a return putaway efficiency of 600 pieces/hour/person
--Through grid storage + visual picking, the efficiency of mixed case picking increased more than 3 times
--Outbound efficiency 400 pieces/hour/person, inbound efficiency 600 cases/hour/person, reducing inbound/outbound time
--Inventory information and pick information in real time significantly improves the reliability of information system
