Xinning Logistics
The Value We Bring to Our Customer
6,006
Storage Locations
4 times
Increase Picking Efficiency
160%
Storage Density
99.9%
Picking Accuracy
Xinning Logistics
Xinning Logistics mainly engages in bonded storage service of electronic components, providing third-party comprehensive logistics service of raw materials, procurement, and production in the electronic information industry’s supply chain. The company’s SMT supply warehouse provides on-site logistics services for the production line of the Lenovo factory in Wuhan. The warehouse had difficulties managing the large amount of SKUs. The project focused on the transformation of the customer’s manual SMT feeding process into an intelligent, flexible, and automatic one.
--Large number of SKUs, difficult to manage
--High requirements for delivery timeliness and large peak shipments
--Pick-by-paper, high error rate, resulting in more time for picking order review.
--Difficulty in SMT board management
Our Solution
--Robot quantity & type: 5 units, A42
--Charging stations：2
--Workstation type & quantity: 3 sets on-robot picking workstation
--Shelving height: 3,100mm
--Case type/size: tote 600mm(L)×400mm(W)×220mm(H)
--Warehouse area: 1,500㎡, storage area: 893㎡, achieving 6,006 storage locations
--The warehouse adopted 3.1-meter shelves. Totes have different grids for small materials. Storage density increased 1.6 times
--Accurate material information management. Supports picking error/correction
--Picking efficiency increased 4 times
--The IQC process was simplified
--Anti-static facilities were implemented to ensure the safety of the warehouse
