Family of HaiPick ACRs

The family of HaiPick Autonomous Case-handling Mobile Robots (ACRs) are ground-based navigators that handle the picking and storage of cases up to 12 meters (39+ feet). A picking arm extends into shelving, up to 2 totes deep, and uses "fingers" to pull and push containers or uncontained goods.

High Efficiency

HaiPick ACRs can batch deliver up to 9 containers in a single run, reducing travel time and maximizing operational efficiency.



Flexible Payload

Picking arm reach and “backpack” dimensions are adjusted to fit the specific items and case types being handled. Mixed container sizes and types can be stored within 1 system.



Case Dimension Range

ACRs can transport containers within these dimensions:

  • 30~80 cm (11.8~31.4 inches) long
  • 20~60 cm (7.8~23.6 inches) wide
  • 10.5~33 cm (4.1~12.9 inches) high
  • Up to 30kg (66 lbs.) per case
  • Compatible with a variety of materials



Safety

CE and NRTL certified.
